Magneto Replacement Kit for Vincent V Twins

Magneto Replacement Kit for Vincent V Twins

by Tri-Spark
$847.72 - $958.07
$847.72
$847.72 - $958.07
$847.72

Bring your classic motorbike back to life with a new electronic ignition!



Product Description

is magneto replacement kit replaces the Lucas KVF (3 bolt flange) magneto originally supplied with the Vincent engine. You won't have any magneto problems as it completely eliminates the magneto with all the benefits of electronic ignition.

  • Fully digital - Extreme spark stability - LED static timing indicator
  • Easy starting without kickback
  • No black box
  • Race proven
  • Extreme temperature safe
  • Idle stabilisation
  • Fits under the Vincent's Magneto cover
  • Avoid the expense of rebuilding your worn out magneto.
  • The electronics are made in Australia

The kit includes Housing, Classic Twin ignition, Dual output coil (IGC-2012), leads and spark plug caps.

For Vincents with Twin Plug Heads the kit includes, Classic Twin ignition, two 6-Volt Dual output coils (IGC-2006), leads and spark plug caps

A battery is required to get the best possible results such as easy starting.

The Magneto Replacement  has electronic advance and retard built in. It requires a solid drive gear (no springs and weights) which is not included in the kit.

You can set the timing statically using the built-in LED on the module - it simply requires that you accurately position the engine at the fully advanced crank position for the setup procedure.

Watch the video demonstration to see the easy starting.

This system is available for two spark plugs per cylinder. Select the 'Twin Spark Plugs Per Head' option from the drop down menu below.

Specifications

MRK-0002, MRK-0020 (Twin Plug Heads)

NOT INCLUDED: It requires a solid drive gear (no springs and weights).

Compatible with:

  • Vincent V Twins

Classic Twin Ignition Specifications:

  • Nominal operating voltage: 12 volts (min 8V max 16V) positive or
  • negative earth (ground)
  • Power consumption including coils: 3A Max (typically 2A)
  • Power consumption at idle: under 1 Amp
  • Coil circuit resistance range: 3.0 to 5.0 Ohms (3.0 absolute minimum)
  • Dwell time: 8 mS nominal with peaks on acceleration and starting
  • Advance range: 12.5 degrees cam or 25 degrees at the crank
  • Fully Advanced: at 3500 RPM
  • Starting range: up to 500 RPM
  • Idle stabilisation range: 500 to 1200 RPM
  • Advancing timing range: 1200 to 3500 RPM
  • Operating temperature range: -20 to 100 degrees Celsius
  • Absolute maximum: 24 volts DC for 1 minute
  • Maximum load dump voltage spike: 180 Volts DC for 50mS
  • Air Gap (rotor to stator unit clearance): 2mm +/- 0.6mm
  • RPM range: 150 to 8000 RPM
  • Size: Stator unit 68mm diameter 10mm thick excluding wires
Instructions and Guides

Magneto Replacement Kit for Vincent V Twins Instruction Booklet

Classic Twin Troubleshooting Guide

Magneto Replacement Kit for Vincent V Twins for Twin Plug Heads Instruction Booklet
